AL-173-AX
High Intensity Portable Lights V2
High-Intensity portable lights for airports battery-powered
POLARIS V2 is a range of lights more compact, designed as portable lights for any type of airports. The light distribution, colorimetry and brightness is as per ICAO Annex 14 standards. The fixtures are durable, and weather-resistant, to ensure visibility while minimizing interference with aircraft operations.
The range includes the following products:
AL-167-06-GR – Threshold – THR – 10000 cd
AL-168-02-RE – Threshold Wing – THR-W – 10000 cd
AL-168-02-RE – Runway End – END – 2500 cd
AL-169-10-WH – Approach – APH – 20000 cd
AL-170-07-WH – Runway Edge Lights – REL – 10000 cd
AL-171-05-GR-RE – Threshold End – THR-END – 10000 cd – 2500 cd
| Category | Portable Lighting Polaris for Airports |
| Product Code | AL-170-07-WH Runway Edge Lights - REL |
Construction
- Case material: aluminum
- Case color: aviation yellow (RAL 1004) powder coating
- Stainless steel fastening elements
- Diffuser: glass
- Battery type: NiMh
Optical
- Light source – high-intensity LEDs with specially designed lenses
- high intensity according to ICAO annex 14, Vol. 1
- optional IR LEDs can be used for NVG compatibility
- there are three beams of light, two of them directional and one omnidirectional for circling. The omnidirectional runway edge lights can be beneficial during a circling approach maneuver.
Electrical specifications
- very low power consumption for 100% brightness
- NiMh battery pack 12 V, 2,7 Ah
Control
- Manual control from the switches on the lamps
- radio control using handheld remote control
- radio control using the base station and POLARIS application
Sensors
- temperature sensor
- GPS
- current and voltage measurement for LEDs
- Battery voltage
- Charging current
- Ambient light sensor
Radio control
- using LORA technology
- 868 MHz for Europe
- 915 MHz for the USA
- direct communication
- coverage – 10 km in direct site of view
Environment
- IP 68 – all lamps are equipped with pressure valves for testing
- anti-condensation breathing valve
- temperature range from -20 to +55 Celsius degrees
- materials resisting the corrosive effects of a saline environment
Charging
- in charger racks
- from solar for permanent or semi-permanent installations
High Intensity Portable Lights V2 Accessories
Φ260mm Base Plate
AL-102-AX
